TECHNICAL DATA OF THE BMW X5.

Select model

Weight

Unladen weight EU in kg 2,185
Max. permissible weight in kg 2,860
Permitted load in kg 750
Permitted axle load front/rear in kg 1,320/1,615
Luggage capacity min. (seats up or roof down) in l 650
Luggage capacity max. (seats down or roof up) in l 1870
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,700
Trailer load 12% (braked) in kg 1,700

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 195 / 265 / 4,000
Engine torque (Nm) at 1/min 620 / 2,000-2,500
Compression ratio : 1 16.5

Performance

Top speed in km/h 230
Acceleration 0-100 km/h in s 6.5

Fuel consumption

Urban in l/100 km 7.4-6.7
Extra-urban in l/100 km 6.5-5.7
Combined in l/100 km 6.8-6.1
CO2 combined emissions in g/km 183
Electricity consumption combined in kWh/100km -
Tank capacity, approx. in l 80

Wheels

Tyre dimensions front 275/35 R22
Tyre dimensions rear 315/30 R22
Wheel dimensions and material front 9.5 J x 22 inches, light-alloy
Wheel dimensions and material rear 10.5 J x 22 inches, light-alloy

Weight

Unladen weight EU in kg 2,510
Max. permissible weight in kg 3,150
Permitted load in kg 715
Permitted axle load front/rear in kg 1,390/1,810
Luggage capacity min. (seats up or roof down) in l 500
Luggage capacity max. (seats down or roof up) in l 1720
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,700
Trailer load 12% (braked) in kg 2,700

Engine

Cylinders/valves 6/4
Capacity in ccm 2998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 210/286/5,000-6,000
Engine torque (Nm) at 1/min 450/1,500-3,500
Compression ratio : 1 11.0

Performance

Top speed in km/h 235
Acceleration 0-100 km/h in s 5.6

Fuel consumption

Urban in l/100 km -
Extra-urban in l/100 km -
Combined in l/100 km 2.0-1.7
CO2 combined emissions in g/km 52
Electricity consumption combined in kWh/100km 23.5-21.5
Tank capacity, approx. in l 69

Wheels

Tyre dimensions front 275/40 R21
Tyre dimensions rear 315/35 R21
Wheel dimensions and material front 9.5 J x 21 inches, light-alloy
Wheel dimensions and material rear 10.5 J x 21 inches, light-alloy

Fuel consumption, electricity consumption and CO2 emissions of the BMW X5.

BMW X5 xDrive40i:
Fuel consumption in l/100 km (combined): 10.7–8.9
CO2 emissions in g/km (combined): 244–204

BMW X5 xDrive45e:
Fuel consumption in l/100 km (combined): 1.7–1.2
CO2 emissions in g/km (combined): 40–27
Electricity consumption combined in kWh/100 km: 27.7–24.3

Official data on fuel consumption, CO2 emissions, power consumption and electric range were determined in accordance with the mandatory measurement procedure and comply with Regulation (EU) 715/2007 valid at the time of type approval. In case of a range, figures in the WLTP take into account any optional equipment. For newly type-tested vehicles since 01.01.2021, the official data no longer exist according to NEDC, but only according to WLTP. For more information on the WLTP and NEDC measurement procedures, see www.bmw.de/wltp

For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html

Read more

Fuel consumption, electricity consumption and CO2 emissions of the BMW X5.

  • Official data on fuel consumption, CO2 emissions, power consumption and electric range were determined in accordance with the mandatory measurement procedure and comply with Regulation (EU) 715/2007 valid at the time of type approval. In case of a range, figures in the WLTP take into account any optional equipment. For newly type-tested vehicles since 01.01.2021, the official data no longer exist according to NEDC, but only according to WLTP. For more information on the WLTP and NEDC measurement procedures, see www.bmw.de/wltp

    For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html
