BMW 3 Series Sedan: Engines & Technical Data

TECHNICAL DATA OF THE NEW BMW 3 SERIES SEDAN.

^{1 ,}²
Powertrain type	Petrol – Plug-in-Hybrid
Power in kW (hp)	215 (292) ³
Torque in Nm	420 ³
Transmission	8-speed, automatic
Drivetrain	Rear-wheel drive

¹
Cylinders	4
Displacement in cm3	1,998
Nominal power in kW (hp)/1/min	135 (184) / 5,000 - 6,500
Nominal torque in Nm/1/min	300 / 1,350 - 4,000

^{2 ,}⁴
(Nominal) power/30-minutes-power in kW (hp)	80 (109)
(Nominal) torque in Nm	265


Acceleration 0–100 km/h in s	5.9
Top speed in km/h	230
Electric top speed in km/h	140

^{1 ,}⁵
Combined fuel consumption from ECO Sticker result in km/l ⁶	71.4
CO2 emissions, combined in g/km ⁶	33
Energy consumption, combined WLTP in kWh/100 km ⁶	19.2
Electric range, WLTP in km ⁷	101

⁸
Battery capacity in kWh	19.5
Maximum charging power AC in Kw	11
Minimum charging time AC 0–100% state of charge in h	2:15


4,713 mm
1,827 mm
1,446 mm
Length in mm	4,713
Width in mm	1,827
Height in mm	1,446
Width incl. mirrors (driver / passenger side) in mm	2,068
Wheelbase in mm	2,851
Vehicle curb weight in kg ⁹	1,910
Permissible gross weight in kg	2,360
Payload in kg	525
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ¹⁰	1,500 / 75
Luggage capacity in l	375
Tank capacity in l	40

¹
Powertrain type	Petrol
Power in kW (hp)	285 (387)
Torque in Nm	500
Transmission	8-speed, automatic
Drivetrain	All-wheel drive

¹
Cylinders	6
Displacement in cm3	2,998
Nominal power in kW (hp)/1/min	285 (387) / 5,800 - 6,500
Nominal torque in Nm/1/min	500 / 1,800 - 5,000


Acceleration 0–100 km/h in s	4.3
Top speed in km/h	230

^{1 ,}⁵
CO2 emissions, combined in g/km	0


4,714 mm
1,827 mm
1,440 mm
Length in mm	4,714
Width in mm	1,827
Height in mm	1,440
Width incl. mirrors (driver / passenger side) in mm	2,068
Wheelbase in mm	2,851
Vehicle curb weight in kg ⁹	1,770
Permissible gross weight in kg	2,245
Payload in kg	550
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ¹⁰	1,800 / 75
Luggage capacity in l	480
Tank capacity in l	59

¹
Powertrain type	Diesel
Power in kW (hp)	140 (190)
Torque in Nm	400
Transmission	8-speed, automatic
Drivetrain	Rear-wheel drive

¹
Cylinders	4
Displacement in cm3	1,995
Nominal power in kW (hp)/1/min	140 (190) / 4,000
Nominal torque in Nm/1/min	400 / 1,750 - 2,500


Acceleration 0–100 km/h in s	7
Top speed in km/h	235

^{1 ,}⁵
Combined fuel consumption from ECO Sticker result in km/l	23.8
CO2 emissions, combined in g/km	112


4,713 mm
1,827 mm
1,440 mm
Length in mm	4,713
Width in mm	1,827
Height in mm	1,440
Width incl. mirrors (driver / passenger side) in mm	2,068
Wheelbase in mm	2,851
Vehicle curb weight in kg ⁹	1,645
Permissible gross weight in kg	2,140
Payload in kg	570
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ¹⁰	1,600 / 75
Luggage capacity in l	480
Tank capacity in l	59

¹
Powertrain type	Petrol
Power in kW (hp)	285 (387)
Torque in Nm	500
Transmission	8-speed, automatic
Drivetrain	All-wheel drive

¹
Cylinders	6
Displacement in cm3	2,998
Nominal power in kW (hp)/1/min	285 (387) / 5,800 - 6,500
Nominal torque in Nm/1/min	500 / 1,800 - 5,000


Acceleration 0–100 km/h in s	4.3
Top speed in km/h	250

^{1 ,}⁵
CO2 emissions, combined in g/km	0


4,714 mm
1,827 mm
1,440 mm
Length in mm	4,714
Width in mm	1,827
Height in mm	1,440
Width incl. mirrors (driver / passenger side) in mm	2,068 (1,040 / 1,028)
Wheelbase in mm	2,851
Vehicle curb weight in kg ⁹	1,770
Permissible gross weight in kg	2,245
Payload in kg	550
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ¹⁰	- / 75
Luggage capacity in l	480
Tank capacity in l	59

^{1 ,}²
Powertrain type	Petrol – Plug-in-Hybrid
Power in kW (hp)	215 (292) ³
Torque in Nm	420 ³
Transmission	8-speed, automatic
Drivetrain	Rear-wheel drive

¹
Cylinders	4
Displacement in cm3	1,998
Nominal power in kW (hp)/1/min	135 (184) / 5,000 - 6,500
Nominal torque in Nm/1/min	300 / 1,350 - 4,000

^{2 ,}⁴
(Nominal) power/30-minutes-power in kW (hp)	80 (109)
(Nominal) torque in Nm	265


Acceleration 0–100 km/h in s	5.8
Top speed in km/h	230
Electric top speed in km/h	140

^{1 ,}⁵
Combined fuel consumption from ECO Sticker result in km/l ⁶	71.4
CO2 emissions, combined in g/km ⁶	33
Energy consumption, combined WLTP in kWh/100 km ⁶	19.2
Electric range, WLTP in km ⁷	101

⁸
Battery capacity in kWh	10.5
Maximum charging power AC in Kw	3.7
Minimum charging time AC 0–100% state of charge in h	4


4,713 mm
1,827 mm
1,444 mm
Length in mm	4,713
Width in mm	1,827
Height in mm	1,444
Width incl. mirrors (driver / passenger side) in mm	2,068 (1,040 / 1,028)
Wheelbase in mm	2,851
Vehicle curb weight in kg ⁹	1,845
Permissible gross weight in kg	2,290
Payload in kg	520
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ¹⁰	- / 75
Luggage capacity in l	375
Tank capacity in l	40

¹
Powertrain type	Diesel
Power in kW (hp)	140 (190)
Torque in Nm	400
Transmission	8-Speed Steptronic transmision
Drivetrain	Rear-wheel drive

¹
Cylinders	4
Displacement in cm3	1,995
Nominal power in kW (hp)/1/min	140 (190) / 4,000
Nominal torque in Nm/1/min	400 / 1,750 - 2,500


Acceleration 0–100 km/h in s	7
Top speed in km/h	235

^{1 ,}⁵
Combined fuel consumption from ECO Sticker result in km/l	23.8
CO2 emissions, combined in g/km	112


4,713 mm
1,827 mm
1,440 mm
Length in mm	4,713
Width in mm	1,827
Height in mm	1,440
Wheelbase in mm	2,851
Vehicle curb weight in kg ⁹	1,530
Luggage capacity in l	480
Tank capacity in l	59

¹
Powertrain type	Petrol
Power in kW (hp)	285 (387)
Torque in Nm	500
Transmission	8-automatisch
Drivetrain	All-wheel drive

¹
Cylinders	6
Displacement in cm3	2,998
Nominal power in kW (hp)/1/min	285 (387) / 5,800 – 6,500
Nominal torque in Nm/1/min	500 / 1,800 – 5,000


Acceleration 0–100 km/h in s	4.3
Top speed in km/h	250

^{1 ,}⁵
Combined fuel consumption from ECO Sticker result in km/l	13.3
CO2 emissions, combined in g/km	171


4,714 mm
1,827 mm
1,440 mm
Length in mm	4,714
Width in mm	1,827
Height in mm	1,440
Wheelbase in mm	2,851
Vehicle curb weight in kg ⁹	1,745
Luggage capacity in l	480
Tank capacity in l	59

¹
Powertrain type	Petrol
Power in kW (hp)	180 (245)
Torque in Nm	400
Transmission	8 - automatic
Drivetrain	All-wheel drive

¹
Cylinders	4
Displacement in cm3	1,998
Nominal power in kW (hp)/1/min	180 (245)/4,500–6,500
Nominal torque in Nm/1/min	400/1,600–4,000


Acceleration 0–100 km/h in s	5.7
Top speed in km/h	250

^{1 ,}⁵
Combined fuel consumption from ECO Sticker result in km/l	7.8–7
CO2 emissions, combined in g/km	176–158


4,713 mm
1,827 mm
1,445 mm
Length in mm	4,713
Width in mm	1,827
Height in mm	1,445
Wheelbase in mm	2,851
Vehicle curb weight in kg ⁹	1,670
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ¹⁰	1,800/75
Luggage capacity in l	480
Tank capacity in l	59

1 Performance data of petrol engines apply to vehicles using RON 98 fuel. Fuel consumption data apply to vehicles using reference fuels in accordance with EU Regulation 715/2007. Unleaded RON 91 and higher with a maximum ethanol content of 10% (E10) may also be used. BMW recommends RON 95 fuel. For high-performance automobiles, BMW recommends RON 98 fuel.

2 For plug-in hybrid: Electric drive depending on battery charging level.

3 Composed of combustion engine drive (specified nominal value) and electric drive (up to specified nominal value). Electric drive depending on battery charging level.

4 For plug-in hybrid: At temperatures below freezing, the fully electric drive system is only available after a few kilometres of driving, once the battery has heated to operational temperature.

5 Official data for fuel consumption, CO2 emissions, power consumption and electric range was determined in accordance with the prescribed measuring procedure and corresponds to European Regulation (EC) 715/2007 in the applicable version. For ranges, data determined as per WLTP takes into account any optional equipment (available on the German market in this case). For vehicles that have been newly type approved since 1 January 2021, only the official data according to WLTP exists. For more information about NEDC and WLTP measuring procedures visit www.bmw.com/wltp

6 For plug-in hybrid: Weighted, combined (EC AC Charge Weighted)

7 Range depends on various factors, in particular: individual driving style, route characteristics, outside temperature, heating/air conditioning, pre-conditioning.

8 The charging performance depends on the state of charge, ambient temperature, individual driving profile and use of auxiliary consumers. The ranges shown are based on the WLTP best case. The charging times apply to ambient temperatures of 23 degrees Celsius after a preceding drive and may differ depending on the usage behaviour.

9 The EC unladen weight refers to a vehicle with standard equipment and does not include any optional extras. The unladen weight includes a 90% full tank and a driver weight of 75 kg. Optional equipment may affect the weight of the vehicle, the payload and the top speed if the selected equipment has an impact on the vehicle's aerodynamics.

10 Trailer load depends on the vehicle options

Consumption and CO2 emissions.

BMW 320d M Sport:
Fuel consumption combined in km/l(combined): 22.7
CO2 emissions in g/km (combined): 115

BMW 330e M Sport:
Fuel consumption combined in km/l(combined):47.6
CO2 emissions in g/km (combined): 48

BMW M340i xDrive:
Fuel consumption combined in km/l(combined):13.3
CO2 emissions in g/km (combined): 171
